High-Precision Stainless Steel Pipes for Demanding Applications
Our TIG-welded stainless steel pipes are built for strength, dimensional accuracy, and corrosion resistance. Manufactured under strict quality control using certified raw materials, they are ideal for structural, mechanical, and fluid transport systems across industries such as automotive, and energy.
Reliable Tubing Solutions Engineered for Consistency
STS stainless steel pipes offer the perfect balance of durability, weld integrity, and smooth internal surfaces. Produced in compliance with EN and ASTM standards, they are suitable for both high-pressure environments and decorative installations where aesthetics and performance matter.
Diameter
(mm)		 Thickness (mm)
0.50 0.60 0.70 0.80 1.00 1.20 1.50 2.00 2.50 3.00
7.5 0.088 0.104 0.119 0.134 0.163 0.189
8 0.094 0.111 0.128 0.144 0.175 0.204
10 0.119 0.141 0.163 0.184 0.225 0.264 0.319
11 0.131 0.156 0.181 0.204 0.25 0.294 0.357
12 0.144 0.171 0.198 0.224 0.275 0.325 0.394 0.501
13 0.157 0.186 0.216 0.244 0.3 0.355 0.432 0.551
13.5 0.163 0.194 0.224 0.254 0.313 0.37 0.451 0.576
14 0.169 0.201 0.233 0.264 0.326 0.385 0.47 0.601
15 0.182 0.216 0.251 0.284 0.351 0.415 0.507 0.651
16 0.194 0.231 0.268 0.304 0.376 0.445 0.545 0.701
17.2 0.209 0.249 0.289 0.329 0.406 0.481 0.59 0.761
18 0.219 0.261 0.303 0.345 0.426 0.505 0.62 0.801
19 0.232 0.276 0.321 0.365 0.451 0.535 0.657 0.851
20 0.244 0.291 0.338 0.385 0.476 0.565 0.695 0.901 1.096
21.3 0.26 0.311 0.361 0.411 0.508 0.604 0.744 0.967 1.177 1.375
22 0.269 0.322 0.373 0.425 0.526 0.625 0.77 1.002 1.221 1.427
25 0.367 0.426 0.485 0.601 0.715 0.883 1.152 1.409 1.653
25.4 0.493 0.611 0.727 0.898 1.172 1.434 1.683
26.9 0.395 0.459 0.523 0.649 0.772 0.954 1.247 1.527 1.795
28 0.479 0.545 0.676 0.805 0.995 1.302 1.596 1.878
29 0.565 0.701 0.835 1.033 1.352 1.659 1.953
30 0.514 0.585 0.726 0.865 1.070 1.402 1.722 2.028
31 0.605 0.751 0.895 1.108 1.452 1.784 2.103
31.75 0.62 0.77 0.918 1.136 1.49 1.831 2.16
32 0.549 0.625 0.776 0.925 1.146 1.502 1.847 2.178
33.7 0.659 0.819 0.977 1.209 1.588 1.953 2.306
34 0.665 0.826 0.986 1.221 1.603 1.972 2.329
35 0.685 0.851 1.016 1.258 1.653 2.035 2.404
36 0.705 0.876 1.046 1.296 1.703 2.097 2.479
38 0.745 0.926 1.106 1.371 1.803 2.222 2.629
40 0.785 0.977 1.166 1.446 1.903 2.348 2.779
42.4 0.833 1.037 1.238 1.536 2.023 2.498 2.96
45 1.102 1.316 1.634 2.153 2.661 3.155
48.3 1.184 1.415 1.758 2.319 2.867 3.403
50 1.227 1.466 1.822 2.404 2.974 3.531
50.8 1.247 1.49 1.852 2.444 3.024 3.591
56 1.377 1.647 2.047 2.704 3.349 3.981
60.3 1.485 1.776 2.209 2.92 3.618 4.304
63.5 1.565 1.872 2.329 3.08 3.819 4.545
70 1.728 2.067 2.573 3.405 4.226 5.033
76.1 2.251 2.802 3.711 4.607 5.491
Diameter
(mm)		 Thickness (mm)
0.50
7.5 0.088
8 0.094
10 0.119
11 0.131
12 0.144
13 0.157
13.5 0.163
14 0.169
15 0.182
16 0.194
17.2 0.209
18 0.219
19 0.232
20 0.244
21.3 0.26
22 0.269
Diameter
(mm)		 Thickness (mm)
0.60
7.5 0.104
8 0.111
10 0.141
11 0.156
12 0.171
13 0.186
13.5 0.194
14 0.201
15 0.216
16 0.231
17.2 0.249
18 0.261
19 0.276
20 0.291
21.3 0.311
22 0.322
25 0.367
26.9 0.395
Diameter
(mm)		 Thickness (mm)
0.70
7.5 0.119
8 0.128
10 0.163
11 0.181
12 0.198
13 0.216
13.5 0.224
14 0.233
15 0.251
16 0.268
17.2 0.289
18 0.303
19 0.321
20 0.338
21.3 0.361
22 0.373
25 0.426
26.9 0.459
28 0.479
30 0.514
32 0.549
Diameter
(mm)		 Thickness (mm)
0.80
7.5 0.134
8 0.144
10 0.184
11 0.204
12 0.224
13 0.244
13.5 0.254
14 0.264
15 0.284
16 0.304
17.2 0.329
18 0.345
19 0.365
20 0.385
21.3 0.411
22 0.425
25 0.601
25.4 0.493
26.9 0.523
28 0.545
29 0.565
30 0.585
31 0.605
31.75 0.62
32 0.625
33.7 0.659
34 0.665
35 0.685
36 0.705
38 0.745
40 0.785
42.4 0.833
Diameter
(mm)		 Thickness (mm)
1.00
7.5 0.163
8 0.175
10 0.225
11 0.25
12 0.275
13 0.3
13.5 0.313
14 0.326
15 0.351
16 0.376
17.2 0.406
18 0.426
19 0.451
20 0.476
21.3 0.508
22 0.526
25 0.601
25.4 0.611
26.9 0.649
28 0.676
29 0.701
30 0.726
31 0.751
31.75 0.77
32 0.776
33.7 0.819
34 0.826
35 0.851
36 0.876
38 0.926
40 0.977
42.4 1.037
45 1.102
48.3 1.184
50 1.227
50.8 1.247
56 1.377
60.3 1.485
63.5 1.565
70 1.728
Diameter
(mm)		 Thickness (mm)
1.20
7.5 0.189
8 0.204
10 0.264
11 0.294
12 0.325
13 0.355
13.5 0.37
14 0.385
15 0.415
16 0.445
17.2 0.481
18 0.505
19 0.535
20 0.565
21.3 0.604
22 0.625
25 0.715
25.4 0.727
26.9 0.772
28 0.805
29 0.835
30 0.865
31 0.895
31.75 0.918
32 0.925
33.7 0.977
34 0.986
35 1.016
36 1.046
38 1.106
40 1.166
42.4 1.238
45 1.316
48.3 1.415
50 1.466
50.8 1.49
56 1.647
60.3 1.776
63.5 1.872
70 2.067
76.1 2.251
Diameter
(mm)		 Thickness (mm)
1.50
10 0.319
11 0.357
12 0.394
13 0.432
13.5 0.451
14 0.47
15 0.507
16 0.545
17.2 0.59
18 0.62
19 0.657
20 0.695
21.3 0.744
22 0.77
25 0.883
25.4 0.898
26.9 0.954
28 0.995
29 1.033
30 1.070
31 1.108
31.75 1.136
32 1.146
33.7 1.209
34 1.221
35 1.258
36 1.296
38 1.371
40 1.446
42.4 1.536
45 1.634
48.3 1.758
50 1.822
50.8 1.852
56 2.047
60.3 2.209
63.5 2.329
70 2.573
76.1 2.802
Diameter
(mm)		 Thickness (mm)
2.00
12 0.501
13 0.551
13.5 0.576
14 0.601
15 0.651
16 0.701
17.2 0.761
18 0.801
19 0.851
20 0.901
21.3 0.967
22 1.002
25 1.152
25.4 1.172
26.9 1.247
28 1.302
29 1.352
30 1.402
31 1.452
31.75 1.49
32 1.502
33.7 1.588
34 1.603
35 1.653
36 1.703
38 1.803
40 1.903
42.4 2.023
45 2.153
48.3 2.319
50 2.404
50.8 2.444
56 2.704
60.3 2.92
63.5 3.08
70 3.405
76.1 3.711
Diameter
(mm)		 Thickness (mm)
2.50
20 1.096
21.3 1.177
22 1.221
25 1.409
25.4 1.434
26.9 1.527
28 1.596
29 1.659
30 1.722
31 1.784
31.75 1.831
32 1.847
33.7 1.953
34 1.972
35 2.035
36 2.097
38 2.222
40 2.348
42.4 2.498
45 2.661
48.3 2.867
50 2.974
50.8 3.024
56 3.349
60.3 3.618
63.5 3.819
70 4.226
76.1 4.607
Diameter
(mm)		 Thickness (mm)
3.00
21.3 1.375
22 1.427
25 1.653
25.4 1.683
26.9 1.795
28 1.878
29 1.953
30 2.028
31 2.103
31.75 2.16
32 2.178
33.7 2.306
34 2.329
35 2.404
36 2.479
38 2.629
40 2.779
42.4 2.96
45 3.155
48.3 3.403
50 3.531
50.8 3.591
56 3.981
60.3 4.304
63.5 4.545
70 5.033
76.1 5.491

You May Also Like

FAQ

TIG welded pipes are produced using Tungsten Inert Gas welding, providing excellent control, clean seams, and strong mechanical properties. They are ideal for applications requiring aesthetic appearance and superior corrosion resistance.



Laser welded pipes, on the other hand, use focused laser beams for ultra-narrow weld seams, allowing high-speed production with minimal heat distortion. This method is suited for high-volume, precision-driven manufacturing.

Our minimum order quantity varies depending on the product type, dimensions, and stainless steel grade. Standard production typically starts from one production batch, but we also accommodate smaller project-based quantities upon request. Contact us with your specifications and we will provide an exact MOQ for your order.

Typical delivery times range from 2 to 6 weeks, depending on product complexity, material grade availability, and order volume. Custom or non-standard profiles may require additional processing time. We always provide a precise delivery schedule during the quotation process to help you plan your project efficiently.

Yes. We provide custom cut-to-length services to meet specific installation or production requirements. Pipes and profiles can be cut with high precision according to your measurements, helping you reduce waste and streamline assembly on-site.

Absolutely. Our products comply with leading European and international standards, including EN 10217-7, EN 10296-2, ISO 9001:2015, ISO 14001:2015, ISO 45001:2018, and additional certifications upon request. Full inspection reports and material certificates are available to ensure traceability and technical reliability.

We manufacture pipes, profiles, and special shapes in a wide range of stainless steel grades, most commonly 304, 304L, 316, and 316L, as well as other grades depending on mechanical or corrosion-resistance requirements. If your project requires a specific alloy, our team will help you determine availability and suitability.

Yes. Our engineering and sales teams provide personalized technical support to help you select the optimal stainless steel solution based on application, load requirements, environment, and industry standards. Whether you need pipes, standard profiles, or custom-engineered shapes, we’re here to assist you at every step.
